| Place of Origin: | China |
| Brand Name: | Metalwork |
| Certification: | CE, ISO, CCC |
| Model Number: | DNW-100KVA*10 |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Plywooden package |
| Delivery Time: | 40 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 sets per month |
| Usage: | Wire Mesh Welding | Voltage: | 3 Ph, 380V, 50Hz |
|---|---|---|---|
| Rated Capacity: | 100KVA | Rated Duty Cycyle: | 50% |
| Color: | Blue, Grey Or Customized | Warranty: | 1 Year |
| High Light: | automatic pipe welding machine,automatic welding equipment |
||
Application:
Widely used for each kinds of fence , hardware mesh, goods shelf, cages, wire frame, steel plate stiffener and others multiple spot welding.
Features:
There are FOUR types:
1. Manual feeding type: Manual place the precut wires into mesh mold, start the welding machine and welding a row in turn, then manual push mold to next row for automatic welding until finish a complete mesh.
2. Semiautomatic feeding type: Manual place the precut wires into mesh mold, automatic step feeding to welding position and welding a row automatically, then automatic draw the mesh mold to next welding position and automatic welding until to finish a complete mesh, then mesh mold automatic back to origin and get out the mesh.
3. Automatic Double Mold Feeding Type: Adopted double layers type or tandem type automatic welding fixtures, and combined advanced PLC , human machine interface and precision servo motor driven system to obtain the continuous feeding and welding automatically.
Machine included double mold for alternating welding, if one performed welding, then another can be placed wires at same time. So the machine can continues working to improve production efficiency.
4. Full automatic feeding type: Equipped automatic hopper for cross wire feeding, line wire automatic feeding as setting length through automatic mesh drawing system.
Technical Parameters:
|
Wire Diameter /mm |
Time /cycle |
15% reduction amount | 30% reduction amount | ||||
|
Welding pressure /N |
Welding current /A |
Solder joint shear resistance /N |
Welding pressure /N |
Welding current /A |
Solder joint shear resistance /N |
||
| Hard-drawn wire | |||||||
| 3.2 | 8 | 556 | 1800 | 4300 | 1160 | 1700 | 5000 |
| 4.80 | 14 | 1600 | 3300 | 8900 | 2670 | 5000 | 10700 |
| 6.40 | 19 | 2600 | 4500 | 16500 | 3780 | 6700 | 18700 |
| Hot-drawn wire | |||||||
| 3.2 | 8 | 556 | 2800 | 3300 | 1160 | 2800 | 3800 |
| 4.80 | 14 | 1600 | 5100 | 6700 | 2670 | 5100 | 7500 |
| 6.40 | 19 | 2600 | 7100 | 12500 | 3780 | 7100 | 13400 |
Workpiece:
FAQ:
Q1: What about your standard delivery date ?
A: Usually 30-40 days. Our company provide just-in-time delivery
Q2: Do your factory sale directly ?
A: YES,it is our factory sale directly, competitive price with high quality and excellent after-sale service.
Our quality products have been export to many countries, such as Russia, USA, Canada, Argentina, Peru,Turkey, Iran, Bazil, Spain, South Asia and Middle East countries.
Q3: Do you have CE Certificate?
A: YES, we have.
Q4: Can you export machines by your factory?
A; YES, we can.
Q5: Will you send engineer to help installing the welding machine?
A : Yes, if need,we can send our engineer to go to your factory to help installing our welding machine, train the workers and make sure the welding machine running well before he leave.
Q6: If the machine get damaged, what can I do?
A: In the guarantee time (1 year), we will send the spare parts to you for free. And provide the technical
consultant for anytime. If more terrible, we can send our engineers to your factory.
We will provide same good after-sale service as the pre-sale service, any of your questions,
we will be replied within 12 hours.
