Hydraulic Hot Roll Mild Steel Slitting Line Trapezium Cutting Machine Start From Blank Sheet
Product Details:
Place of Origin: China
Brand Name: Metalwork
Certification: CE, ISO, CCC
Model Number: 6x1600
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: Plywooden box
Delivery Time: 40 days
Payment Terms: L/C, T/T
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
Voltage: 380V,3PH,50HZ Or Customerized Material: Q235 Or Q345 Mild Steel
Slitting Coil Width: 1600mm Max Cutting Length: 14000mm
Usage: Light Pole Production Power: 4KW
High Light:

light pole bending machine

,

cut to length line machine



Hydraulic Hot Roll Mild Steel Slitting Line



The trapezium cutting machine is specially designed for pole raw material sheet cutting, before bending, It can be the main part of the cut to length line, also can be separated purchased by the customer who want to save investment for the beginners.



The light pole plate trapezium cutting machine is base on the rolling shearing principle to cutting the lightpole taper steel and get trapezium steel plate. There is a dolly in the front of the slitting unit. it is for control the taper cutting degree. Through changing the base position on dolly to change the taperdegree.





TECHNICAL FEATURES
Name Unit Value
Max. Cutting Thickness Mm 2.5~6
Max.plate width Mm 1600
Max. inner Width of double slitting unit Mm 1600
Max. inner Width of taper slitting unit Mm 1800
Max. Cutting Length Mm

12000 or 14000

(according requirments)

Slitting speed m/min. 12
Power of the motor Kw 5.5+5.5
Overall size

40x3m( for 12m light pole),

or 46x3m( for 14m light pole)









































Technical Process:



Transport coil→loading coil→un-coiler→press and guide→feeding and leveling →cutting head→store material→guide→press material→slitting→store material→collect edge→pre-divided material,damping→press divided material→rolling→unloading(hydraulic pneumatic control, electric control)



Application:



It is for lamp post material to cut the scrap edge of the sheet two sides, and slitting the sheet into 3 pieces or 2 pieces to get one side small and one side big width.
