FL-3015-1500W Fiber Laser Cutting Machine
FL-3015-1000W sheet metal laser cutting machine uses of gantry double drive structure,high precision rack rail drive, Baichu Cypcut CNC laser cutting system, high precision collision Laser cutting head,reinforced welding bed, the whole stable and reliable, flexible operation and simple, high-speed drilling to achieve cutting function, professional cutting all kinds of sheet metal, precision accessories, hardware tools, gifts and other metal materials.
Application Scope and Material:
1. Mild steel
2. Stainless steel
3. Aluminum
4. Copper
5. Galvanized sheet
Product Structure:
Features:
- Max. accelerated speed can reach 1.5g.
- X/Y repeated positioning accuracy can reach: ±0.03mm.
- Adopt Global No.1 ALPHA rack & pinion and speed reducer in the world.
- Adopting Switzerland advanced laser cutting head, position precisely, avoid undulate plate
deformation, then gets qualified cutting seam.
- Adopting advanced laser, such as Racus, IPG, etc., stable performance, the useful life of key parts can reach 100 thousand hours.
- Max. cutting speed can reach 100m/min.
- Economic price and excellent aftersales service, within 24hours response.
- Low Processing costs, saving water, electricity and gas.
Main Components:
Technical Parameters:
| Processing Area |
3000mm X 1500mm |
| Max Cutting Speed |
100m/min |
| Max accelerated |
1.5G |
| X/Y Positioning Accuracy |
0.05mm/m |
| X/Y Repeated Positioning Accuracy |
±0.03mm |
| Power supply |
380V 50Hz |
| Laser Power |
500W-1200W |
| Gross power |
＜10KVA (not include fiber laser generator or water chiller) |
| Machine running temperature |
0℃-40℃ |
| Running humidity |
＜90% |
| Whole machine weight |
4000kg |
| Machine dimensions |
4600*2750*1500mm |
| Transmission |
Precise pinion and rack,dual-drive transmitting |
1500W Cutting Parameters:
| Material |
Optimal Thickness Range (mm) |
Maximum Practical Thickness (mm) |
Key Considerations |
| Carbon Steel |
0.5 – 10 |
12 – 14 |
Oxygen-assisted cutting. Excellent quality up to 10mm. Cutting 12-14mm is slow with noticeable taper and rough edges. Not suitable for production at maximum thickness. |
| Stainless Steel |
0.5 – 6 |
8 – 10 |
Requires high-purity nitrogen. Good quality up to 6mm. 8-10mm requires very high gas pressure (>16 bar), slow speeds, and results in reduced edge quality. |
| Aluminum |
0.5 – 4 |
6 – 8 |
High reflectivity makes cutting challenging. Nitrogen assist recommended. Good quality up to 4mm. 6-8mm produces heavy dross and requires frequent maintenance. |
| Brass |
0.5 – 3 |
4 – 6 |
Nitrogen assist essential due to zinc fumes. 3mm is practical limit for quality cuts. 4-6mm is possible but with heavy dross, contamination risk, and poor edge quality. |
| Copper (Pure) |
0.5 – 2 |
3 – 4 |
Extremely challenging. ABR/RFT protection mandatory. Reliable only up to 2mm. 3-4mm is absolute limit with very slow speeds and frequent failures. |
Cutting Samples:
Questions:
1. Are you a trading company or factory?
--- We are factory occupying more than 100,000 m2, with excellent and professional technical team, 25 R&D personnel, professional after-sales team, and around 200 workers producing more than 1000 sets machines each year.
2. Does your company supply and build the machines to suit customer's needs and specifications?
--- Yes, we can custom-made the machine according to your requirements.
3. What is your advantages over your competitors' machine?
--- Our machines can be equipped with high configuration, and main components are from famous brands. We have strict quality control system, process technology system, technology innovate system.
4. Does the machine come with a guarantee?
--- We offer one year of warranty, during this time, if any parts broken, we will send a new one to customer free of charge, and we will also supply on-line the technical guidance for ever free.
5. Can I go to visit your factory?
--- Welcome to visit our factory to know our processing and technology power. And you will see different sample machine at our workshop.
6. How to get quicker quotation?
--- When you send us inquiry, please offer your requirement information:
• What kind of metal plate and the thickness?
• What’s the size of your workpiece?
These information is helpful for us to choose suitable equipment solution and price quickly.
