Product Details:
Place of Origin: China
Brand Name: Metalwork
Certification: CE, ISO, CCC
Model Number: CNC2-1500X3000
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: 1 x 20' GP
Delivery Time: 40 days
Payment Terms: L/C, T/T
Supply Ability: 100 sets per month
Contact Now
Detailed Product Description
CNC System: China Fangling, USA Hypertherm Plasma Source: USA Hypertherm, Victor, Chinese LGK Series
Height Controller: Hongyuda XPTHC-100V Nesting Software: FastCAM Professional Version, InteGNPS
Motor: Japan Panasonic Reducer: Japan Shimpo
High Light:

cnc steel cutting machine

,

plasma metal cutting machine



1500X3000mm Hyperthem CNC Plasma Metal Sheet Cutting Machine Table Type with FastCAM



Product Description:



The heavy bed of plasma cnc cutting machine makes the equipment more stable in working, the light crossbeam of plasma cnc cutting machine makes it work faster; plasma cnc cutting machine's perfect industrial design is more in line with man-machine engineering; high quality electrical software control system gives equipment higher cutting precision. The plasma cnc cutting machine owns more comfortable operation, more stable performance, more durable quality, higher cutting efficiency and wider application scope.

1) Space saving, quick installation, no foundation request.

2) Using integrated modular structure, making installation quick and easy.

3) High accuracy servo motor dirve.

4) Friendly operation panel, easy-to-use.

5) Automatic program optimization nest path.

6) USB data transmission.

7) The machine size can be customized.



Components of Plasma Cutting Machine:



A: Main machine structure including: beam, moving parts, pipe parts, transverse slide line rack, vertical and transverse transmission parts and so on.



B: Plamsa torch or flame torch.



C: Electric control box including: electric cabinet, longitudinal and transverse motors and accessories.



D: Gas assembly including: general pipe for three way of gas supplyelectromagnetism valvepressure gaugetemper preventing equipment and so on.



E: Height adjusting controller: Torch Height Controllor (can cut different height material).



F: USA Hypertherm, USA Victor, Chinese LGK series plasma source.







1500X3000mm Hyperthem CNC Plasma Metal Sheet Cutting Machine Table Type with FastCAM 0

Technical Parameters:



Model CNC2-1500 CNC2-2000
Effective cutting width 1500mm 2000mm
Effective cutting length 2000-6000mm
Driving speed 0~24000mm/min
Guide precision ±0.2mm
Vertical precision ±0.3mm
Integrated line precision ±0.5mm
Cutting precision German D/N 2310 standard industrial grade standard
Cutting torch quantity 1
Cutting method Flame or dry type plasma or fine plasma



Cutting Samples:



Rapid exchanging between two platforms greatly improve work efficiency. Rack and pinion transmission system has better rigidity and higher accuracy, saving feeding time, making operation more efficient. The highest speed of platform exchanging is 10s.



1500X3000mm Hyperthem CNC Plasma Metal Sheet Cutting Machine Table Type with FastCAM 1



Application:

Table type CNC plasma cutting machine for steel, copper, aluminum and stainless steel, which are widely used for Ship Building, Construction Equipment, Transport Equipment, Aerospace Industry, Bridge Building, military industrial, wind power, Structural Steel, Boiler containers, Agriculture Machinery, Chassis electrical cabinets, Elevator manufacturers, Textile Machinery, Environmental protection equipment,ect.

Machine photo:



1500X3000mm Hyperthem CNC Plasma Metal Sheet Cutting Machine Table Type with FastCAM 2
