HB Tilting Pipe Welding Equipment Positioner For Automatic Pipe Circular Welding

HB Tilting Welding Positioner

The welding positioner includes various types and it is usually combined with automatic welding system, such as manipulator and welding machine. With gyration and upturning of working table, the welding and fitting can be located at the right position. If connected with other welding devices, it can be turned into a half-automatic or full automatic welding machine. The gyration of working table can use electromagnetic speed variation or frequency control.

Because of eccentricity and gravity, it is better to choose a bigger type for long workpiece or those with too much gravity center deviation. The shape and weight of workpieces, process and working method are provided, our company shall supply a prompt scheme your reference.

Features:

•  It includes light and heay duty type, L type, head&tail type, 2 axis type, turning table, etc.

•  It can realize rotating at 360° and tilting at 0°-90°/120°, and it can be used with welding.

•  It adopts frequency inverter to control the rotation speed to ensure rotating smoothly.

•  Various loading capacity from 100 kgs to 50 tons.

•  Limited switch and remote controller to ensure the positioning accuracy and safety.

•  ABB, Schneider or Siemens electric parts adopted in our machine.

•  Customized or non-standard available to customer's special requirements.

Technical Parameters:

Application:

1. Pressure vessels
2. Pipe manufacturing industries
3. Wind power fabrication
4. Chemical & fuel storage tank fabrication
5. Any heavy cylindrical job

Product Display:

•  The rotary of worktable adopts frequency control, it can rotate infinitely.

•  The welding positioner has big tilting angle, tilting range is from 0~120°.

•  It adopts gear transmission, the gear is durable and has long service line after forging.

•  There’s concentric tick mark with T type slot, which is convenient for fixing the work-piece.

•  According to the rated capacity of different specifications can be customized.
